Description

Silent Knight SK-Relaymon-2

This module i s, capable of monitoring two separate Class B circuits. They combined with two Form C relay outputs. They save you time and money by reducing what may have taken four modules. To accomplish a single module footprint.

Combines two relay outputs and two monitor inputs into one module device. The module i s capable of Class B supervised wiring to the monitored devices. It contains Form C relay contacts allowing the panel to switch the contacts on command. Each monitor input provides an interface. B etween a fire alarm control panel and one or more normally open contact-type devices. Each relay output has its green LED. They mount directly into a 4” square electrical box. The box must have a minimum depth of 2-1/8”. A surface-mount electrical box (System Sensor® PN SMB500) i s available from Silent Knight.

Features / Specifications

Monitor two circuits, with unique addresses.

Two Form C relay contacts with each having a unique address

Fully supervised support for Class B input wiring

Relay programming is completely flexible – can b e mapped to zone conditions

Individual LED’s for each monitored input and relay output

Rotary address switches for fast installation
