Description

The System Sensor SRA is a white strobe with selectable strobe settings of 15, 15/75, 30, 75, 95, 110 and 115 cd. This model offers the most versatile and easy-to-use line of horns, strobes, a horn strobes in the industry. With white and red plastic housings, wall and ceiling mounting options, and plain and FIRE-printed devices, SpectrAlert Advance can meet virtually any application requirement.

To further simplify installation and protect devices from construction damage, the System Sensor SRA utilizes a universal mounting plate with an onboard shorting spring, so installers can test wiring continuity before the device is installed.

SpectrAlert Advance horns, strobes, and horn strobes shall mount to a standard 4 × 4 × 1½-inch back box, 4-inch octagon back box, as well as double-gang back box. Two-wire products shall also mount to a single-gang 2 × 4 × 17⁄8-inch back box. Also, a universal mounting plate used for mounting ceiling and wall products.

Features / Specifications

• Automatic selection of 12- or 24-volt operation
• Universal mounting plate for wall units
• Mounting plate shorting spring checks wiring continuity before device installation
• Electrically Compatible with legacy SpectrAlert devices
• Compatible with MDL3 sync module
• Listed for ceiling or wall mounting
