Description

Gentex GES24-30WR Evacuation Strobe

The Commander2 Series is a low-profile strobe.
The GE Series is available in fixed candela options of 15/75 and 177.
The Commander2 Series horn offers a continuous temporal three. All tones are easy for the professional to change in the field by using switches.
The product features a locking mechanism which secures the product to the bracket without any screws showing.
The Commander2 Series features the patented Checkmate®Instant Voltage Verification feature which allows the installer to check the voltage drop draw and match it to the blueprint.
I. INTRODUCTION
The Gentex models are high-quality audible and/or visible signaling appliances. The high-intensity strobe utilizes a Xenon flash tube. These items are provided with a slider switch which allows for candela selection at the installation site.

Emergency and General Signaling. Colored lens models comply with the polar dispersion requirements of ANSI/UL 1971.
II. LOCATION
This appliance – intended for use in Fire Alarm Systems and is to – installed by this manual, the recommendation of the local authorities having jurisdiction, and other NFPA documents that provide standards on notification appliances for protective signaling systems. Intended for indoor installations only; this appliance – not listed for outdoor or drip-proof applications.

III. MOUNTING, ROUGH-IN BOX AND RUN WIRING
This unit – designed for mounting to most single gang boxes, 4″ square outlet boxes, 2-gang masonry boxes, or non-metallic 2-gang switch boxes. Conduit entrance to boxes – selected to ensure sufficient wiring clearance.
1. Run a minimum of 18 gauge insulated 2 or more conductor cables.
2. Mount a box for each remote signaling appliance. Screw the bracket onto the box. Insert the signal into the bracket and slide to the right firmly into the terminal block
receptacle.
