Description

Edwards GSA-MRM1 Riser Monitor Module

Intelligent analog addressable devices. That forms part of Edward’s Signature line of products.

Depending on their assigned personality. Riser Monitor Modules used to monitor telephone risers. Use 70 Vac audio, 25 Vac audio, or 12 Vdc to 24 Vdc risers. The fire alarm control panel indicates an alert status. The Riser Monitor Module requires one module address.

Edwards GSA-MRM1 – a part of the UIO family of plug-in Signature Series modules. The GSA-RM1 takes advantage of the modular flexibility and easy installation. That characterizes all UIO modules.  These accommodate individual risers for each on-board module or risers shared by any combination of its UIO modules. All wiring connections – made to terminal blocks on the motherboard. UIO assemblies mounted in Edwards enclosures.

Electronic Addressing
Setting complicated switches or dials – not required. Each module has its unique
serial number stored in its “on-board memory”. The loop controller identifies each device on the loop and assigns a “soft” address
to each serial number. If desired, the modules – addressed using the SIGA-PRO Signature Program/Service Tool.
Personality Codes
Signature modules require the Signature loop controller to download the personality code that determines how it will operate.
The Riser Monitor Module provides personality codes 23 and 24.
Personality Code 23: Riser Monitor (factory default)
Personality code 23 configures the Riser Monitor Module. To monitor 70 Vac audio, 25 Vac audio, or 12 Vdc and 24 Vdc risers. A trouble condition – reported back to the panel wherever the voltage on the riser drops below the trouble threshold.
Personality Code 24: Telephone Riser Monitor
Personality code 24 configures the Riser Monitor Module to monitor telephone risers.
Warnings & Cautions
This module will not operate without electrical power.
