Description

Edwards 116EX-P Explosion Proof Pendant Mounting Module

The 116 Class Fire Alarm Strobe Lights, available in gray housing or red housing – in-rush current limited strobe lights.
The strobe – intended for indoor use in UL 1971 (signal appliance for the hearing impaired) listed compatible fire alarm systems. The strobe flashes a 360-degree beam of light approximately 65 times per minute. With a UL 1971 125 cd ceiling and 60 cd wall light output. With the guard installed, the strobe flashes a beam with an output of 86 cd ceiling and 51 cd wall. Other applications require electrical supervision of the signaling circuit field wiring. The strobe – rated for outdoor use in Canada. The 116 Class strobes – cUL listed to Canadian Standard ULCS526-07 (Visual Signal Device for Fire Alarm Systems). Suitable for indoor and outdoor applications. The strobe features an enhanced synchronization circuit to comply with the latest requirements of UL 1971 and CAN/ULC-S526-07.
Synchronized operation requires a separately installed synchronization control module. See Table 1 on page 5 for a list of compatible synchronization modules.

This strobe is UL and cUL-listed as a Type 3R and 4X enclosure.

Install the pendant mount module, Cat. No. 116EX(R)-P, to the 116 main housing. Tighten setscrew. Install an explosion-proof hanger box. Secure 3/4″ NPT threaded conduit to the box. Install the unit on the conduit. Ensure the conduit engages. Secure the pendant mount module to the conduit. Connect the field earth ground wire to the ground screw or earth ground via a conduit system.

Edwards 116EX-P Explosion Proof Pendant Mounting Module

Datasheet
